Chinaware Ball Mill

Chinaware Ball Mill

Charge Amount: 0.05-15 tons per time

Reference Power: 2.2-75kw

Application Range: Suitable for mixing and grinding common and special materials.

Features: Even fineness and power conservation


    Brief Introduction to Chinaware Ball Mill

    Chinaware ball mill is mainly used for mixing and milling materials, which is also known as ceramic ball mill. This grinding miller is warmly welcomed due to the even output fineness and low energy consumption.

    Chinaware Ball Mill

    Application of Ceramic Ball Mill

    The advantages of ceramic ball mill or Chinaware ball mill include low investment, low energy consumption, novel structure, simple operation, safe operation, etc. Ceramic ball mill is suitable for mixing and grinding common and particular materials. Users can choose the proper type according to actual situations.

    Chinaware Ball Mill

    Chinaware Ball Mill

    Parameters of Chinaware Ball Mill

    Model Feeding capacity
    Shell rotation speed
    Reference motor
    Liner material
    600×700 0.05 50 2.2 Chinaware,silicon,rubber or metal(the related motor power varied as per the different liner materials and grinding materials)
    800×600 0.075 42 3
    900×1200 0.2 38.5 5.5
    1300×1500 0.5 33 7.5
    1500×1800 1.2 28.5 11
    1800×2000 1.5 24 15
    2600×2800 5 16.5 37
    3000×3800 10 14.5 57.2
    3200×4600 15 13.5 75
