Electromagnetic Vibrating Feeder

Electromagnetic Vibrating Feeder

Condition: New
Production Capacity: 5-100t/h
Supply Ability: 35 Set/Sets per month
Feature: Without lubrication, simple structure, easy maintenance
Features

    Electromagnetic vibrating feeder is a kind of linear feeding equipment. It features in smooth vibrating, reliable operation and long service life. It is  widely used in mining, building materials, silicate and chemical industries for crushing and screening.

    Electromagnetic Vibrating Feeder

    Characteristics

    (1) Small cubage, light weight, simple structure and easy maintenance.

    (2) Electric magnetic feeder uses less electric energy due to the employment of the engine vibrating resonance principle.

    (3) The feeding size is highly accurate because it can change and start or shut material flow instantaneously.

    (4) The damage to the chute is little because the material in the chute is continuously swung up when being fed in.

    Technical Parameters of Electromagnetic Vibrating Feeder

    Model
    Items
    Feeding
     capacity
    (t/h)
    Max. Feeding
    size(mm)
    Power
    (w)
    Voltage(v) Electric
    current(a)
    Double
    amplitude
    (mm)
    Clearance
    (mm)
    Total
    weight
    (kg)
    GZ1 5 50 60 220 1≤ 1.75 1.9-2.2 75
    GZ2 10 60 150 220 2.3≤ 1.75 1.9-2.2 155
    GZ3 25 70 200 220 3.8≤ 1.75 1.9-2.2 225
    GZ4 50 100 450 220 7≤ 1.75 1.9-2.2 460
    GZ5 100 150 650 220 10.6≤ 1.75 1.9-2.2 656
