The Temperature Measurement Methods of Rotary Kiln

Date:08/04/2014 08:12:56

Rotary kiln belongs to building materials equipment, which can grind raw materials into clinker with the help of high temperature. Rotary kiln is the main equipment of cement production process, so it is also known as cement rotary kiln. In order to ensure the safe operation of rotary kiln, the kiln shell temperature detection system has been developed. The system presents full the advantages of the computer, which can realize real-time acquisition the surface temperature signal of the rotary kiln, and then after the analysis and recognition process, the output will be printed or stored on the disk for long-term preservation. The system fully makes up for the deficiency of the artificial handheld infrared thermometer to reduce the interference of human factors. The surface temperature can be a reliable monitoring of the rotary kiln, so as to improve the accuracy of the dangerous points forecast for cylinder body.

There are main two temperature measurement methods of rotary kiln: the contact method or non-contact method, of which the contact measurement method is most commonly used, insert temperature sensor in the rotary kiln axis position to directly measure the of rotary kiln temperature, and then the electric signals will appear through the slip ring and external which are fixed on the brush system of the rotary kiln body. The advantages of this method are that the measurement signals can directly reflect the kiln temperature, and measuring method is simple with less investment. But this method also has fatal weaknesses, one is the serious wear slip ring and brush system, so the signal contact is not good, which often need to change with signal fluctuation; another is due to the high temperature of thermocouple protection tube under impact, abrasion, and corrosion cause the thermocouple protection of the tube's life is very short, sometimes just install the thermocouple, because mechanical collision caking material is in the kiln, protective sleeve will soon damage; the third is the signal obtained by this method is difficult to use for the closed-loop control.
